150F Metal False Ceiling
150F Interior / Exterior Interior
Material Panels 150mm wide x 17mm deep, made out of 0.60mm aluminium alloy AA 3105/3105/5052 with stove enamelled coil coated finish / 0.50mm galvanised steel with stove enamelled coil coated finish. (Colour according to TRAC® colour chart and availability chart). Panel length upto approx 5m
Stringers
34.5mm wide, 48mm deep made out of 0.95mm aluminium alloy AA5052/0.60mm galvanised steel, with prongs to hold the panels in a module of 75 /150mm.
Suspension
By means of suspension rods and spring clips.
Panel Span
1.5m max. with insulation, 1.8m max. without insulation
Stringer Span
1.5m max. spacing of suspension rods.
Finish
Coil Coated Panels will be finished on exposed side with 20 microns polyester coil coating over primer and on the rear side with a wash coat.
Material
Panels
150mm wide x 17mm deep, made out of 0.60mm aluminium alloy AA 3105 / 5050 with stove enamelled coil coated finish / 0.50mm galvanised steel with stove enamelled coil coated finish. (Colour according to Trac colour chart and availability chart). Panel length up to approx 5m.
Stringers
34.5mm wide, 48mm deep made out of 0.95mm aluminium alloy AA 5052/0.60mm galvanised steel, with prongs to hold the panels in module of 150mm.
Suspension
By means of rigid suspension angles or mounted on a steel sub-structure.
Panel Span
1000mm max.
Stringer Span
500mm max. spacing of suspension angles.
Finish
Coil Coated Panels will be finished on exposed side with coil coated stove enamelled PVF2/ polyurethane/SMP paint with a wash coat on rear side.
